FLASHTRAB Arrester Phoenix Contact adalah perangkat penahan surge petir /tegangan kejut petir atau juga di sebut dengan tegangan paku yang di desain untuk mampu membelokkan arus yang besar diletakkan sisi depan jaringan daya atau di istilahkan arrester tahap 1 / level I.
Secara fungsi arrester ini akan membelokkan tegangan kejut petir dan mengalirkannya menuju ground, perletakan arrester di jalur awal (setelah meter PLN atau Genset) karena alat ini akan mampu menahan tegangan dan arus kejut yang besar akan tetapi masih ada kemungkinan terlepasnya arus petir (surge). Terlepasnya arus petir ini disebabkan oleh keterbatasan peralatan (komponen) yang ditanam di FLASHTRAB.
Jadi arrester level 1 adalah peralatan arrester yang diletakkan di sisi depan jaringan daya dan apabila terjadi kelebihan tegangan akan melepas tegangan lebih ke grounding.
Ada 2 tipe :
FLASHTRAB Compact Plus
- Single-Phase
- Two-Phase
- Three-Phase
- N/PE spark Gap
- Replacement Connector
FLASHTRAB FLT-PLUS
- Spark Gap with Quenching Aid
- Encapsulated Spark Gap
- N/PE Spark Gaps
FLASHTRAB Compact Plus
FLASHTRAB Compact Plus
FLT-CP-PLUS-1S-350
Neutral Conductor and earth Separate (N and PE)
Pluggable lighting current arrester, in acc. with type 1/class I/B for 1-phase power supply networks with separately installed PE and N (L1, PE, N).
FLT-CP-PLUS-1C-350
Neutral Conductor and earth Combined (PEN)
Pluggable lighting current arrester, in acc. with type 1/class I/B for 1-phase power supply networks with combined PE and N (L1, PEN) installed in one cable.
FLT-CP-PLUS-3S-350
Neutral Conductor and earth Separate (N and PE)
Pluggable lighting current arrester, in acc. with type 1/class I/B for 3-phase power supply networks with combined PE and N (L1, L2, L3, PE, N).
FLT-CP-PLUS-3C-350
Neutral Conductor and earth Separate (PEN)
Pluggable lighting current arrester, in acc. with type 1/class I/B for 3-phase power supply networks with combined PE and N (L1, L2, L3, PEN) installed in one cable.
FLT-CP-N/PE-350
Encapsulated pluggable Class I arresters as N/PE spark gap with an ignition mechanism for triggering the sparkover voltage.
FLT-CP-PLUS-350-ST
Type 1 / Class I / B arrester (lightning arrester) replacement plug for paths L-N and L-PEN, can be combined with FLASHTRAB compact series of products.
FLT-CP-N/PE-350-ST
Type 1 / Class I / B arrester (lightning arrester) replacement plug for path N-PE, can be combined with FLASHTRAB compact series of products.
FLASHTRAB FLT-PLUS
FLASHTRAB FLT-PLUS
1. Spark Gap with Quenching Aid
Type 1 / Class I / B arrester (lightning current arrester) with arc chopping spark gap and ignition electronics with control lamp, quenching plates for high mains follow-through current quenching capacity, 1-channel. Protection level: 0.9 kV. Housing width: 35 mm (2 Div.)
Type 1 / Class I / B arrester (lightning current arrester) with arc chopping spark gap and ignition electronics, quenching plates for high mains follow-through current quenching capacity, 1-channel. Protection level: 2. kV. Housing width: 35 mm (2 Div.)
Type 1 / Class I / B arrester (lightning current arrester) with arc chopping spark gap and ignition electronics with control lamp, quenching plates for high mains follow-through current quenching capacity, 1-channel. Protection level: 2.5 kV. Housing width: 35 mm (2 Div.)
2. Encapsulated Spark Gap
